Nexcom VTK-SCAP
• SuperCap Battery Back Up (BBU) for In-Vehicle/Railway Application
• Communication - RS232
• Capability - Up to 200W for 1m27s with expansion (3 slave power boxes)
• Compatible with Nexcom vehicle/railway PCs
Product Description
Get in Touch
Our highly experienced and friendly staff are here to answer your question and to assist you in selecting the right mobile system for your requirements.
Call us on 01691 900222
Email [email protected]
Nexcom VTK-SCAP SuperCap BBU for In-Vehicle/Railway Applications in Extreme Environments
The VTK-SCAP is a high-performance rechargeable battery back-up (BBU) designed for NEXCOM vehicle and railway computers. It offers uninterrupted power and a sophisticated power management system. With enhanced charge/discharge efficiency and an RS232 interface for status monitoring, VTK-SCAP provides reliable backup power. It can deliver a maximum output power of 200W. In expansion mode (1 x VTK-SCAP-M + 3 x VTK-SCAP-S), VTK-SCAP can support a 60W system for up to 6 minutes. Leveraging supercapacitor technology, VTK-SCAP is suitable for extreme environments, operating reliably from -35°C to 80°C.
Main Features:
- SuperCap BBU for in-vehicle/Railway application
- High power density EDLC (Electric Double Layer Capacitor) technology
- Over 500,000 cycle life (charging/discharging)
- Operating Temperature: -35~80°C
- SDK for software development
- RS232 for communication
- Max. expansion 1 x master + 3 x slave
Models available:
- The VTK-SCAP-M is the Master for in-vehicle.
- The VTK-SCAP-AR-M model is Master for railway (with EN50155 certification)
- The VTK-SCAP-S model is Slave for expansion.
| Specs | Description |
|---|---|
| Physical | VTK-SCAP-M, VTK-SCAP-AR-M, 235mm (W) x 134.5mm (D) x 50mm (H) |
| Physical | VTK-SCAP-S, 235mm (W) x 134.5mm (D) x 50mm (H) |
| Power | Input: 9~60VDC, Output: 24 VDC |
